Contact Angle Meter
Measurement of Contact Angle
The contact angle is an easy measurement method to determine the wettability of a solid substrate by a liquid. When depositing a droplet onto a solid substrate, the liquid will form a drop shape. The point where the solid, the liquid and vapor meet, is called the three-face point and it determines the contact angle. The contact angle is also an indicator for the wettability, which is dependent on the combination of solid substrate and liquid, as well as on the environment.
The relationship between the contact angle, the solid surface free energy, the liquid surface tension and the interfacial tension between solid and liquid is defined by the Young equation:
γS = γL cosθ + γSL
θ: Contact angle
γS: Surface free energy of the solid
γL: Surface tension of the liquid
γSL: Interfacial tension between solid and liquid
In general, the following rule applies: The larger the contact angle the worse the wettability, the lower the contact angle the better the wettability.
